Motovario BA Helical Bevel Gearbox – Aluminium
Sizes: A40-A50-A70. Available versions: BA – fitted for motor coupling, IBA – with input shaft, CBA – with compact motor. Cases with feet, flange or universal. Power up to 4,8 Kw. Gears with shaved or ground profile. Gearing with 2 and 3 reduction stages. Hypoid bevel gears for size A40 and A50, gleason bevel gear pairs for size A70, all with run-in profile. Reduction ratios between 7,62 and 442,76. Torque max 450 Nm and admissible radial loads max 5.500 N on hollow shaft and 10.000 N on solid shaft. Cases in die-cast aluminium alloy. Excellent mechanical strength while being and particularly lightweight. Load capacity calculated to ISO6336 and verified according to AGMA 2001-B88. Painted with RAL 5010 blue epoxy-polyester powder in according to DIN 1843. Accessories: torque arm, output flange, output shaft.
